Description
Technical Specifications
Output
Nominal Output Voltage
120V
Input
Nominal Input Voltage
120V
Input frequency
50/60 Hz +/- 5 Hz (auto sensing)
Input Connections
NEMA 5-15P
Cord Length
6ft (1.83meters)
Number of Power Cords
1
Surge Protection and Filtering
Surge energy rating
840Joules
Physical
Maximum Height
11.5inches (292MM, 29.2CM)
Maximum Width
2.25inches (57MM, 5.7CM)
Maximum Depth
1.5inches (38MM, 3.8CM)
Net Weight
1.0lbs. (0.45KG)
Shipping weight
1.33lbs. (0.6KG)
Shipping Height
13.3inches (338MM, 33.8CM)
Shipping Width
5.8inches (147MM, 14.7CM)
Shipping Depth
1.5inches (38MM, 3.8CM)
Color
Charcoal
Master Carton Dimensions (Length x Width x Height)
16inches
Master Carton Units
12.0
Master Carton Weight
18.52lbs. (0.0)
Units per Pallet
288.0
SCC Codes
1073130421102 7
Environmental
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 {99e2bc16a2f6d40b2a16a7637b1c60ce0a7435dfb88ca3fa80c384b418f7dc87}
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 {99e2bc16a2f6d40b2a16a7637b1c60ce0a7435dfb88ca3fa80c384b418f7dc87}
Storage Elevation
0-50000ft (0-15000meters)
Conformance
Approvals
CSA, UL 1449
